Important Attributes

Application	Road	Material	Stainless steel
Types	Square, Taper, Polygonal, Dual-Arm, Single-Arm, Round, Octagon	Origin	Jiangsu, China
Thickness	3M-12M	Product weight (kg)	90
Characteristics	Waterproof, high brightness, durable, easy to install, and environmentally friendly	Surface treatment	Hot-dip galvanizing, powder coating
Lighting solution services	Lighting distribution and circuit design, auto CAD design drawings, engineering installation services	Wind-resistant	180 km/h, 200 km/h
Warranty period (years)	5 years	Product name	Lamp Pole
Keyword	Street light pole	Size	custom size
Color	Customer's Request	Material	Q235, Q345, Iron, Steel
Surface treatment	Hot Hip Galvanization	Application	Highway, Road
Style	Morden	OEM/ODM	Accepted
Design	OEM ODM

Product Introduction

Technical Specification Comparison: Decano 10m vs. 11m Street Lamp Poles

For large-scale highway and infrastructure projects, choosing between a 10m and an 11m pole often depends on the required lighting uniformity and local wind load standards. At Decano, both heights are engineered using high-strength Q235 steel with a focus on structural stability and long-term anti-corrosion.

Decano 10 Meter & 11 Meter Pole Parameters

Technical Specification	10-Meter Pole	11-Meter Pole
Application Focus	Main Urban Roads / Secondary Highways	Main Highways / Expressways / Ports
Top Diameter (mm)	80 - 90 mm	90 - 100 mm
Bottom Diameter (mm)	180 - 200 mm	200 - 220 mm
Wall Thickness (mm)	3.5 - 4.5 mm	4.0 - 5.0 mm
Section Design	2-Section (5m + 5m)	2-Section (5.5m + 5.5m)
Material Grade	Q235 / Q345 Hot-Rolled Steel
Surface Protection	Hot-Dip Galvanized (ISO 1461) + RAL Powder Coating
Wind Load Rating	Up to 150 km/h	Up to 160 km/h (Reinforced)
Base Plate (mm)	400 x 400 x 20 mm	450 x 450 x 22 mm
Anchor Bolts (J-Bolts)	4 x M24 x 1000mm	4-6 x M27 x 1100mm
Avg. Weight (Approx.)	145 - 175 kg	180 - 220 kg

Key Design Considerations for 11m Infrastructure:

Increased Luminous Coverage: The 11 Meter Street Lamp Pole allows for a wider light distribution (Type III or Type IV), which is ideal for multi-lane expressways. It enables even greater pole spacing (up to 40 meters), significantly reducing the total project cost for poles and installation.
Enhanced Structural Taper: Decano's 11m poles feature a larger bottom-to-top taper ratio. This design naturally channels wind pressure and reduces the oscillation of the All-in-One Solar Light or heavy-duty brackets at the top.
Logistics Optimization: Both heights are manufactured in a 2-section telescopic slip-joint format. This ensures they fit perfectly into a 40HQ container, maximizing your shipping ROI and protecting the galvanized finish during transit.
Foundation Stability: Due to the increased leverage of an 11m height, Decano provides a reinforced base plate design and a deeper
Foundation Cage blueprint to ensure safety in soft soil or high-wind coastal zones.

Decano: Engineering Strength for Global Infrastructure.

Need a customized CAD drawing for an 11-meter highway project? Contact the Decano technical team for a free Dialux simulation and a wholesale container-load quote today!

Specification

Product Name	Lamp Pole
Size	Customized size
Pole height	Street lamp poles range from 3 meters to 20 meters, Solar street lamp poles range from 4 meters to 16 meters
Shape	Circular, octagonal, straight, square, single-arm, double-arm, polygon
Material	Q235, Q345, iron, steel
Powder coating	Pure polyester powder coating, and the color can be selected according to the RAL color card standard.
