Important Attributes
| Protection index | IP65 | Lighting solution services | Lighting distribution and circuit design, auto CAD design drawings |
| Warranty period (years) | 5 years | Origin | Jiangsu, China |
| Application | Road | Color temperature | 2700K (soft and warm white), 6000K (daylight alert), 3500K (warm white) |
| Light source | Other | Power supply | Photovoltaic, AC, Other |
| Emission Angle (°) | 140 | Certification | ce, CCC |
| Color Rendering Index (Ra) | 80 | Control method | Remote control |
| Input voltage (volts) | 12v DC | Material of the main body of the lamp | Aluminum alloy |
| Luminaire luminous efficacy (lm/w) | 120 | Luminaire luminous flux (lm) | 150 |
| Lamp lifespan (hours) | 50000 | Material | abs plastic |
| Required assembly | yes | Material of lampshade | Plastic |
| Support dimming | yes | Operating temperature (℃) | -20 - 50 |
| Product name | All In One Solar Street Light | Keyword | Solar Street Light |
| Size | 505x260x50mm | Effectiveness | 98% |
| Total harmonic distortion | <15% | Protection level | IP65 |
| Wind resistance index | 10 | Lamp life | >50000h |
| Installation height | 4-6m | Waterproof | IP65 Waterproof |
Product Introduction
30W All-In-One Solar Street Light: Lighting Coverage Guide
Best Installation Height: 5 meters to 6 meters.
Single Lamp Coverage: Approximately 18 meters x 7 meters (Rectangular area).
Recommended Spacing: Install one lamp every 15 meters to 20 meters to ensure continuous road lighting without dark spots.
Optics Design: Features a professional Bat-wing lens. This design stretches light along the road direction, which reduces the total number of poles needed and lowers project costs.
30W Power Consumption Reference (Grid-Power Comparison)
If this 30W light were connected to a standard power grid, its theoretical consumption would be:
Daily Usage: 30W x 10 hours = 300Wh = 0.3 kWh.
Monthly Usage: 0.3 kWh x 30 days = 9 kWh.
Annual Usage: 0.3 kWh x 365 days = Approximately 110 kWh.
Conclusion: The solar version saves approximately 110 kWh of electricity per lamp every year.
Product advantages
1. No battery installation is required
2. No need to install solar panels
3. There is no need to carry out cumbersome construction again
4. It can be easily installed within a few minutes
5. Color and power can be customized
Lighting mode
1. People come to stand out and leave for a long time (overnight).
2. Intelligent power reduction at different time periods
Solar integrated street lamps are a type of lighting fixture that integrates high-efficiency photovoltaic modules, large-capacity lithium battery packs, high-efficiency LED chips, light control, infrared, intelligent controllers and the main body of the lamp.
Specification
| Product Name | Multi-in-one solar street lamp |
| Size |
505x260x50mm |
| Efficacy |
98% |
| Total harmonic distortion |
<15% |
| Protection grade | IP65 grade |
| Working temperature |
Normal temperature type: -20℃ to +50℃ Low-temperature type: -45℃ to +50℃ |
| Wind resistance index |
10 |
| Bulb lifespan |
>50000h |
| Installation height |
4-6m |
